Testing & Accreditations
Exova Warringtonfire the NAMAS/UKAS Accredited Laboratory based in the UK, have tested and passed Caswell Firesafe non-coated ductwork to BS 476 Part 24:1987 Method for determination of the fire resistance of ventilation ducts.
The Caswell Firesafe non-coated fire resisting ductwork system manufactured by Firetrace Ltd is certified by the LPCB (Loss Prevention Certification Board) for up to 4 hours stability and integrity and up to 2 hours insulation to BS 476-24 (1987). LPCB CERTIFICATION gives the end-user client the added reassurance of a fire-rated system that is recognised by insurers.
Manufactured within an ISO9001 accredited purpose built factory, which is regularly audited by LPCB in accordance with the requirements of LPCB:FPC (Factory Production Controls). These controls ensure that every item of ductwork is manufactured to the exacting standards required by Firesafe Fire Rated Ductwork Ltd and compliance with the specification of the tested product.
The table below confirms the system capabilities which apply equally to horizontal and vertical (riser) ductwork and Fire Outside (type test A) and Fire Inside (type test B)
| System Description | Material | Stability & Integrity | Insulation |
|---|---|---|---|
| Ventilation/Smoke Extract/ Pressurisation | Galvanised Mild Steel | Up to 4 Hours | Up to 2 Hours* |
| Ventilation/Smoke Extract/ Pressurisation | Stainless Steel | Up to 4 Hours | Up to 2 Hours* |
| Kitchen Extract | Galvanised Or Stainless | Up to 4 Hours | Up to 60 mins* |
| Kitchen Extract | Mild Steel (Fully Welded) | Up to 4 Hours | Up to 60 mins* |
| Kitchen Extract | Stainless Steel (Fully Welded) | Up to 4 Hours | Up to 60 mins* |
*Insulation values are obtained through the application of specific insulation
All systems are manufactured to satisfy the requirements of recognised ductwork specifications including DW 144 and DW 172
Supply Only Non Coated Fire Rated Ductwork:
- Rectangular duct up to 3000mm square
- Circular duct up to 1250mm diameter
- Special construction duct up to 8m longest side
- Horizontal and vertical orientations
- Available in Galvanised, Mild & Stainless Steel
- Conventional or Fully Welded construction
- Tested for ‘Fire Outside’ & ‘Fire Inside’ scenarios
- Fire rated Access Doors
- Fire rated Silencers
- Bespoke design for ductwork support systems
All fire rated ducting is manufactured to the CASWELL FIRESAFE® specification. Email us now to obtain a quote for your requirements.
The system was developed and tested in the early 2000’s in accordance with BS476 Part 24 (1987). In recent years further, development and testing in accordance with EN1366 Part 1 (2013) to meet European legalisation including CE marking.
The product is tested to BS 476-24 (1987) and EN 1366-1 (2013) for up to 4 hours stability and integrity and up to 4 hours insulation (fire outside duct) and 2 hours insulation (fire inside duct).
Email us now to obtain a quote for your requirements.
